AINAVITO 10-Inch QLED Car Radio User Manual

1. Introduction

This manual provides detailed instructions for the installation, operation, and maintenance of your AINAVITO 10-Inch QLED Car Radio. This unit is specifically designed for Jeep Compass and Patriot models manufactured between 2010 and 2016, offering an upgraded in-car entertainment and navigation experience. Please read this manual thoroughly before use to ensure proper functionality and safety.

Figure 1: AINAVITO 10-Inch QLED Car Radio with included backup camera and a smartphone demonstrating CarPlay/Android Auto functionality.

2. Configuration et installation

2.1 Contenu du paquet

Vérifiez que tous les composants sont présents dans le package :

• 1x Car Head unit with Frame
• 1x câble RCA
• 1x câble d'alimentation
• 1 microphone de voiture
• 1x Antenne GPS
• 1x Frame Removal Tools
• 1x Arrière View 1080P Camera (approx. 16.40 ft cable)
• 2x câbles USB
• 1 câble de commande d'inversion

Figure 2 : Plusview of all components included in the AINAVITO 10-Inch QLED Car Radio package.

2.2 Installation terminéeview

This car stereo is designed for plug-and-play installation, minimizing the need for vehicle modifications. It supports the car's original information display and steering wheel control functions.

Figure 3: Visual comparison of the car's dashboard before and after the installation of the AINAVITO car radio.

2.3 Installation de la caméra de recul

The included AHD 1080P backup camera provides a clear view when reversing. Connect the camera to the designated input on the head unit. Ensure proper routing of the cable to avoid interference and damage.

Figure 4: Details of the Ultra HD 1080P Adjustable Reversing Camera.

3. Mode d'emploi

3.1 Interface utilisateur (UI 3.0)

The device features a customized UI 3.0 with an intuitive desktop layout and editable applications. Navigate through the main interface to access various functions such as navigation, music, radio, and settings.

Figure 5: Main interface of the AINAVITO Car Radio with UI 3.0.

3.2 CarPlay sans fil et Android Auto

Connect your smartphone via Bluetooth or USB cable to access Apple CarPlay or Android Auto. This allows you to use mobile functions like navigation, messaging, and music directly on the car radio display, enhancing driving safety.

Figure 6 : Connectivité sans fil CarPlay et Android Auto.

3.3 Connectivité et navigation

The unit supports 5G WiFi and mobile hotspots for internet access. Built-in Bluetooth 5.0 enables hands-free calls, phone book download, and music playback. With WiFi connected, online GPS navigation is fully functional.

Figure 7: Features including 5G WiFi, GPS Map, FM Radio, and Google Assistant.

3.4 Sound Quality and Equalizer

Experience enhanced audio with the built-in 48-band EQ and various music effects. The professional tuning system allows for personalized sound settings.

Figure 8: 48-band Equalizer for sound customization.

3.5 Écran partagé

The split-screen function allows for simultaneous display of multiple applications, such as navigation and music, or entertainment and phone calls.

Figure 9: Split Screen Display functionality.

3.6 Commande vocale

Utilize voice commands for various functions, including navigation and general queries, with increased sensitivity for ease of use.

Figure 10: Voice control integration with the car radio.

4. Entretien

To ensure the longevity and optimal performance of your AINAVITO Car Radio, follow these general maintenance guidelines:

• Nettoyage: Use a soft, dry cloth to clean the screen and exterior. Avoid abrasive cleaners or solvents that may damage the display or finish.
• Température: Évitez d'exposer l'appareil à des températures extrêmes, chaudes ou froides, pendant des périodes prolongées.
• Mises à jour logicielles : Periodically check for available software updates to ensure you have the latest features and performance enhancements.
• Connexions de câble : Vérifiez que tous les câbles sont bien connectés et en bon état. Des connexions desserrées peuvent entraîner des problèmes intermittents.

5. Dépannage

If you encounter any issues with your AINAVITO Car Radio, refer to the following common troubleshooting steps:

• Pas d'alimentation : Vérifiez toutes les connexions électriques. Assurez-vous que le contact du véhicule est mis. Vérifiez le fusible du câble d'alimentation.
• Pas de son : Check speaker connections. Ensure the volume is not muted or set to zero. Verify audio settings in the system menu.
• Problèmes de connexion Bluetooth : Ensure Bluetooth is enabled on both the car radio and your smartphone. Delete previous pairings and attempt to re-pair. Check the device name and PIN.
• Perte du signal GPS : Ensure the GPS antenna is properly installed and has a clear line of sight to the sky. Move the vehicle to an open area if signal is weak.
• Écran tactile non réactif : Essayez de redémarrer l'appareil. Si le problème persiste, une réinitialisation d'usine peut être nécessaire (attention : cette opération effacera toutes les données utilisateur).
• CarPlay/Android Auto ne se connecte pas : Ensure your phone's operating system is up to date. Try connecting with a different USB cable. Verify that the Zlink application is running correctly on the head unit.

Pour les problèmes persistants non résolus par ces étapes, veuillez contacter le service client.

6. Spécifications

7. Garantie et assistance

AINAVITO is committed to providing satisfactory service. For any installation assistance or technical inquiries, 24-hour after-sale service is available.

7.1 Contacter l'assistance

If you require technical support or have questions regarding your car stereo, please follow these steps:

1. Locate the seller's information on the platform where you purchased the product.
2. Utilize the 'Ask a question' feature to submit your query directly to the seller.

Figure 11: Steps to contact technical support for assistance.
