1. Introduction
This manual provides essential information for the safe and effective use of the Shark W225S Mounted Point. Please read these instructions thoroughly before operation and retain for future reference. The Shark W225S is a multi-purpose abrasive tool designed for various grinding and finishing applications.
2. Consignes de sécurité
AVERTISSEMENT: Always wear appropriate personal protective equipment (PPE) including safety glasses, gloves, and hearing protection when operating abrasive tools. Failure to do so may result in serious injury.
- Ensure the mounted point is securely fastened to the tool before use.
- Do not exceed the maximum operating speed specified for the mounted point.
- Inspect the mounted point for damage or wear before each use. Discard if damaged.
- Gardez la zone de travail propre et bien éclairée.
- Gardez les enfants et les spectateurs éloignés lorsque vous utilisez un outil électrique.
- Évitez tout contact avec les pièces en rotation.
- Do not force the tool; let the abrasive do the work.
Ce produit contient des substances chimiques reconnues par l'État de Californie comme pouvant causer le cancer, des malformations congénitales ou d'autres problèmes de reproduction. Manipuler avec précaution et se laver les mains après utilisation.
3. Installation
The Shark W225S Mounted Point is designed for use with compatible rotary tools or grinders.
- Compatibilité des outils : Verify that your rotary tool or grinder is compatible with a 1-inch diameter mounted point and has a collet or chuck that can securely hold the shank.
- Installation:
- Ensure the power tool is unplugged or its battery is removed before installation.
- Insert the shank of the Shark W225S Mounted Point into the collet or chuck of your rotary tool.
- Tighten the collet or chuck securely to prevent the mounted point from slipping during operation.
- Gently pull on the mounted point to confirm it is firmly seated.
- Préparation de la pièce : Fixez fermement la pièce à usiner dans un étau ou un serre-joint.amp to prevent movement during grinding.
Figure 1: The Shark W225S Mounted Point (salmon color, 1-inch diameter) attached to a rotary tool. This image illustrates the correct installation of the abrasive point into the tool's chuck or collet.
4. Mode d'emploi
- Mise sous tension : With all safety precautions in place, turn on your rotary tool. Start at a lower speed setting if adjustable.
- Application: Gently bring the rotating mounted point into contact with the workpiece. Apply light, consistent pressure.
- Technique de broyage : Move the mounted point smoothly across the surface of the workpiece. Avoid dwelling in one spot, which can cause overheating or uneven material removal.
- Contrôle de vitesse : Adjust the tool speed as necessary for the material and desired finish. Higher speeds are generally for finer finishes, while lower speeds are for heavier material removal.
- Refroidissement: For prolonged use or on heat-sensitive materials, allow the mounted point and workpiece to cool periodically to prevent damage.
- Éteindre: When finished, lift the mounted point from the workpiece before turning off the tool. Allow the tool to come to a complete stop before setting it down.
5. Entretien
- Nettoyage: After each use, clean any debris or dust from the mounted point using a stiff brush or compressed air.
- Inspection: Regularly inspect the mounted point for signs of wear, chipping, or cracking. A worn or damaged point can be inefficient and dangerous.
- Stockage: Store mounted points in a dry, safe place, away from moisture and direct sunlight, to prevent degradation.
- Élimination: Dispose of worn or damaged mounted points responsibly according to local regulations.
6. Dépannage
| Problème | Cause possible | Solution |
|---|---|---|
| Mauvaise élimination des matériaux | Worn mounted point; insufficient speed; incorrect pressure | Replace mounted point; increase tool speed; apply consistent, light pressure |
| Vibrations excessives | Mounted point not securely fastened; bent shank; damaged point | Re-tighten collet/chuck; replace mounted point if shank is bent or damaged |
| Overheating of workpiece/point | Excessive pressure; prolonged contact; too high speed for material | Reduce pressure; use intermittent contact; reduce tool speed; allow cooling periods |
7. Spécifications
- Modèle: W225S
- Taper: Mounted Point
- Couleur: Saumon
- Diamètre: 1 pouces
- Épaisseur: 1 pouces
- Fabricant: Requin
- Numéro de pièce : W225S
- Poids de l'article : 0.353 onces
- Dimensions du produit : 5.5 x 3 x 1.25 pouces (dimensions de l'emballage)
- Pays d'origine : États-Unis
8. Garantie et assistance
For information regarding warranty coverage or technical support for your Shark W225S Mounted Point, please contact the manufacturer directly.
Manufacturer: Shark Industries
Veuillez vous référer à l'emballage d'origine du produit ou au site officiel du fabricant. webConsultez ce site pour obtenir les informations de contact et les détails de garantie les plus récents.
