RANE SYSTEM ONE All-in-One Motorized Standalone DJ Controller

1. Introduction

The RANE SYSTEM ONE is a professional all-in-one motorized standalone DJ controller designed for unparalleled performance and creative freedom. Featuring Engine DJ OS, it allows for laptop-free mixing with 7.2-inch motorized aluminum platters, providing the classic turntable feel preferred by open format DJs. This manual provides essential information for setting up, operating, maintaining, and troubleshooting your RANE SYSTEM ONE.

A DJ actively using the RANE SYSTEM ONE controller, showcasing its illuminated controls and dual platters.

2. Guide de configuration

Follow these steps to get your RANE SYSTEM ONE ready for use.

2.1 Mise sous tension initiale et connexion Wi-Fi

1. Power on the RANE SYSTEM ONE.
2. Connect the device to a Wi-Fi network. This is crucial for updates and streaming services.
3. If a firmware update is available, you will be notified on the screen. Follow the on-screen prompts to update wirelessly.

2.2 Engine DJ Profile and Desktop Software

1. Create an Engine DJ Profile account. This allows for single sign-on for music streaming services and access to community-sourced BPM and key information.
2. Download and install Engine DJ Desktop software on your computer from moteurdj.com.
3. Use Engine DJ Desktop to import your music libraries (e.g., Serato DJ crates, cues, loops) and render tracks for Stems.
4. Export your prepared tracks and playlists to an SD card or USB stick. Ensure the drive is formatted as FAT32 or ExFAT.
5. Safely eject the drive from your computer and insert it into the RANE SYSTEM ONE.

The rear panel of the RANE SYSTEM ONE, highlighting USB, SD card, and other connectivity options.

2.3 Connectivité

The RANE SYSTEM ONE offers extensive input/output options for various setups:

• Sorties principales: XLR and RCA for connecting to main sound systems.
• Sorties de cabine : 1/4-inch for connecting to booth monitors.
• Entrées microphone: Two combo XLR inputs with dedicated EQ and FX.
• Audio Bluetooth: For wireless audio input.
• USB/SD Slots: For media playback and library management.

3. Mode d'emploi

Master the controls and features of your RANE SYSTEM ONE for dynamic performances.

3.1 Track Loading and Navigation

1. Use the touchscreen or browse knobs to navigate through your playlists and tracks on the connected media.
2. Press the left or right knob to load a track to a deck, or double-tap on the screen.
3. You can also load tracks to one of the eight standalone sampfentes pour cartes.
4. Create playlist shortcuts by long-pressing one of the three playlist buttons when a playlist is selected.

Un gros plan view of the RANE SYSTEM ONE's central controls and vertical touchscreen display, showing track waveforms and navigation.

3.2 Stems Technology

The RANE SYSTEM ONE features advanced Standalone Stems Technology for on-the-fly mixing and remixing.

• Access Stems in standalone mode using the Stems pad mode.
• Utilize Instant Acapella and Instrumental buttons for quick vocal and instrumental isolation.
• Control Stems levels precisely with the dedicated Stems Level EQ.

3.3 Effets (FX)

The controller offers a robust arsenal of over 25 Main FX, 5 Sweep FX, 10 Touch FX, and 4 Fader FX.

• Touch FX: Engage by pressing the Touch FX button and selecting an effect from the screen. Adjust parameters by tapping the effect name.
• Main FX: Select and trigger Main FX using the dedicated buttons. Hold a button to access more effect options from the screen.
• Fader FX: Select a Fader FX and adjust its settings by holding down the Fader FX button. Activate by moving a volume fader or the crossfader.
• Balayage FX : Hold the Sweep FX button to choose an effect, then push the button and turn the knob to engage.

Un détail view of the RANE SYSTEM ONE's FX section, showing various effect buttons and parameter controls.

3.4 Diffusion en continu et enregistrement

• Streaming: Play directly from supported streaming services (Apple Music, Amazon Music Unlimited, Beatsource, Beatport, TIDAL, SoundCloud GO+, Dropbox) by pressing the Source button and selecting from the list.
• Enregistrement: Record your sets directly on the device. Access the recording function via the menu.

4. Principales caractéristiques

The RANE SYSTEM ONE is packed with features designed to elevate your DJ experience:

• All-in-One Standalone System: First standalone DJ system with 7.2-inch motorized aluminum platters and Engine DJ OS for laptop-free mixing.
• OMNISOURCE Flexibility: Seamlessly mix between USB-SD, internal drive slot, streaming services, and Serato DJ Pro.
• Serato DJ Pro Integration: Full access to Serato Stems and Scratch Bank with touch navigation and BPM-key sorting.
• Standalone Stems Technology: Mix and remix with Stems, Stems FX, Instant Acapella/Instrumental buttons, and Stems Level EQ.
• Robust FX Arsenal: Over 25 Main FX, 5 Sweep FX, 10 Touch FX, and 4 Fader FX for complex routines.
• Visual Control Center: 7-inch vertical HD touchscreen with customizable RGB waveforms and Day Mode.
• Studio I/O and Workflow: High-fidelity RANE sound with XLR Main, RCA Main, 1/4-inch Booth outputs, Bluetooth audio, two combo XLR mic inputs with EQ and FX, and MAG FOUR crossfader.
• Smart Lighting and Stage Integration: Integrated SoundSwitch compatibility for wireless control of Philips Hue and Nanoleaf smart lights.
• Seamless Library Migration: Use Engine DJ desktop software to import Serato DJ libraries to USB/SD for instant standalone use.

The RANE SYSTEM ONE DJ Controller, highlighting its motorized platters and comprehensive control layout.

5. Entretien

Proper maintenance ensures the longevity and optimal performance of your RANE SYSTEM ONE.

• Nettoyage: Use a soft, dry cloth to clean the surface of the controller. Avoid abrasive cleaners or solvents. For the screen, use a microfiber cloth specifically designed for electronics.
• Protection contre la poussière: Lorsqu'elle n'est pas utilisée, recouvrez la manette pour la protéger de la poussière et des débris.
• Stockage: Conservez l'appareil dans un endroit frais et sec, à l'abri de la lumière directe du soleil et des températures extrêmes.
• Gestion des câbles: Veillez à ce que tous les câbles soient bien rangés et non tendus afin d'éviter d'endommager les ports et les connecteurs.

6. Dépannage

Voici des solutions aux problèmes courants que vous pourriez rencontrer :

• Pas d'alimentation :
  - Ensure the power cable is securely connected to the controller and a working power outlet.
  - Check the power switch on the rear panel.
• Pas de sortie audio :
  - Verify that all audio cables (XLR, RCA, Booth) are correctly connected to your sound system/monitors.
  - Check the master volume, channel faders, and crossfader positions.
  - Ensure the correct input source is selected on your sound system.
• Problèmes de connexion Wi-Fi :
  - Confirm your Wi-Fi network is active and within range.
  - Re-enter the Wi-Fi password to ensure it's correct.
  - Restart the RANE SYSTEM ONE and your Wi-Fi router.
• Tracks Not Loading from USB/SD:
  - Ensure the USB drive or SD card is properly inserted.
  - Verify that the drive is formatted as FAT32 or ExFAT.
  - Check if the tracks were correctly exported using Engine DJ Desktop.
• Stems Not Working:
  - Confirm that the tracks have been pre-rendered for Stems in Engine DJ Desktop.

For further assistance, refer to the official RANE support resources.

7. Spécifications

8. Informations sur la garantie

The RANE SYSTEM ONE comes with a standard manufacturer's warranty. Please refer to the warranty card included in your product packaging or visit the official RANE website for detailed terms and conditions. Keep your proof of purchase for any warranty claims.

9. Assistance clientèle

For technical support, product registration, or additional resources, please visit the official RANE website:

• RANE Official Website: www.rane.com
• Engine DJ Support: www.enginedj.com/support

You can also follow RANE DJ and Engine DJ on social media for the latest tips, tricks, and performance content.
